Introduction
Watch the following video for instructions on how to remove the cadence sensor, and install a torque sensor on the Roguehawk FS eBike. Make sure to scroll down to the extra FAQ for more information to go along with the video!
You will need the following tools to install this:
Phillips Screwdriver
8mm Allen Key
Crank Arm Puller
15mm Wrench for pedals and crank arms
Vernier Calipers
A Digital Set of these will work best
20 Spline Bottom Bracket Removal ToolBBS02
Purchase Here (Canada): Park Tool Shimano/ISIS BBT-22C Bottom Bracket Tool
Purchase Here (USA/International): Park Tool Shimano/ISIS BBT-22C Bottom Bracket Tool
Bafang Ultra Lockring RemovalTool
Purchase Here (Canada): Bafang Ultra/M600/BBSXX Lock Ring Tool
Purchase Here (USA/International): Bafang Ultra/M600/BBSXX Lock Ring Tool
Breaker Bar
Power Drill
Small bits to drill pilot hole
Step bit/bits to drill 1/2" hole
Circular And Flat File
Alternatively, a dremel or other rotary tool will work
Bicycle Parts Grease
Biktrix recommends Park Tool PPL-1 Polylube 1000 Grease
Electrical Tape
Roguehawk Torque Sensor Installation FAQ
You might have to perform some extra changes to your bike to ensure the Torque Sensor works to it's peak ability on your bike:
Shorten your chain
You may have gotten a 52T chainrinng with the Torque Sensor Kit. If this is the case you will need to remove TWO full links from your chain to achieve optimal shifting.
Rear Light not working
If your rear light is not functioning you will need to swap the leads - ensuring the + Lead is connected to the red wire, and the - lead to the black.
This reverses the orientation of the stock controller.
