eBike and Display Compatibility
Looking to upgrade your display? Consult this chart to see which options are compatible with your bike
Bike Model | Compatible Displays |
|---|---|
Juggernaut Classic 8/9 | 500C, 850C, 800S, C965, DPC18 |
Juggernaut Classic Duo | 500C, 850C, 800S, C961, C965, DPC18 |
Juggernaut Lite | DM01, 500C, 850C, 800S, C965, DPC18 |
Juggernaut Hub Duo | 500C, 850C, 800S, C965, DPC18, DM07 |
Juggernaut HD/HD Limited | C965, 500C, 850C, DPC18 |
Juggernaut HD Duo | C965, 500C, 850C, DPC18 |
Juggernaut Ultra 1000 | 500C, 850C, 800S, C965, DPC18 |
Juggernaut Ultra FS/FS Pro 1/2/3 | 500C, 850C, 800S, C965, DPC18 |
Juggernaut Ultra Duo 1/2/3/4 | 500C, 850C, 800S, C965, DPC18 |
Juggernaut FS Step-Thru | DPC010 (CANBUS), CANBUS DPC18, CANBUS 500C |
Juggernaut XD / XD DUO / FS XD | 500C^, DS104, DS103 |
Juggernaut XD Founders Edition | 500C^, DS104, DS103 |
Juggernaut Ultra Founders Edition | CANBUS DPC18, CANBUS 500C |
Juggernaut Ultra Beast 1 | 500C, 850C, 800S, C965, DPC18 |
Juggernaut Ultra Beast 2 | CANBUS DPC18, CANBUS 500C |
Monte Capro Ultra | CANBUS DPC18, CANBUS 500C |
Monte Capro Ultra 2 | 500C, 850C, 800S, C965, DPC18 |
Monte Capro Lite | CANBUS DPC18, CANBUS 500C |
Stunner LT 2019* | S830, M5 |
Stunner LT 5/6/7 | 800S, C961, C965, DPC18, 500C |
Stunner LT 8 | 860C |
Stunner X 4/5/6 | 500C, 850C, 800S, C961, C965, DPC18 |
Stunner Step-Over/Step-Thru 4/5/6 | 500C, 850C, C965, DPC14, DPC18 |
Swift Step-Thru 1/2 | 500C, 850C, 800S, C965, DPC18 |
Swift Step-Over 1^ | 500S (VPT02) |
Swift Step-Over 2 | 500S (VPTO3), 500C, 850C, C965, DPC18 |
Swift Step-Over 3/Step-Thru 3^ | 500S (RS03 V5.8) |
Swift Lite 1 | YL-70E, YL81C-B |
Swift Lite Step-Thru 2/3 | YL-70E, YL81C-B |
Kutty | C600E, KTLCD5 |
Kutty X | C600E, KTLCD5 |
Kutty X 2 | 500C, 850C, 800S, C965, DPC18 |
Kutty LT 3 | DM07, 500C, 850C, 800S, C965, DPC18 |
Skycap 1^ | 800S |
Skycap 2* | CDC6 |
Challenger 1/2* | KD51C |
Moto* | SW900 |
*These models are compatible with only these models of the display. Switching between the original display your bike came with and an alternative display may be a difficult process. Biktrix does not recommend switching the display to another model.
^This model is only compatible with the one display listed here and only a specific version of that display. Contact Biktrix if you need a replacement display and be sure to mention your bike model so you get sent the correct one.
