Introduction
If you are having trouble with our Armageddon light please consult the following guide for some troubleshooting steps.
There is a short video here. Click below for some wiring diagrams pertaining to different installation configurations on the bike.
Note: If you have a newer bike some of the relay wires may be different colours. Consult this table below for information:
Wire/Connection | Old Relay | New Relay |
Bike Negative Power Wire | Red with Yellow Tip | Purple Wire |
Positive Armageddon Light Connection | Red With Blue/Green Tip | Orange Wire |
Positive Headlight Wire Connection | Red with Purple Tip | Red Wire |
Negative Headlight Wire Connection | Black with orange tip | Black Wire |
